Thermal Dynamics® Slide
Airgas Part #:TDC15-2190
Manufacturer Part #:15-2190
Log in to get your price
$8,422.15
Each
$8,422.15
/Each
Item Details
- ESAB industrial linear slides designed for precise torch positioning and adjustment in automated welding and plasma cutting systems. The product line includes the 15-2190 non-motorized mechanical carriage for A-Series equipment and the 0334333882 motorized linear slide for A2 and A6 automation heads.
Features
- Precise torch positioning for automated systems
- Non-motorized design (15-2190) allows for integration or reuse of existing drive mechanisms
- Motorized drive mechanism converts rotary motor energy into linear motion
- Supports joint tracking (PAV) and remote manual positioning
- Versatile mounting for horizontal or vertical adjustments
- Resistant to flux dust and metallic particulates in SAW and MIG/MAG environments
- Electrical impedance and gearing ratios matched to ESAB control architecture
- OEM assembly includes connection leads and installation hardware
Specifications
- Part Number: 15-2190 (Non-motorized)
- Part Number: 0334333882 (Motorized)
- Stroke Length (15-2190): 8 inches
- Stroke Length (0334333882): 180mm
- Motor Voltage (0334333882): 42V DC
- Control Voltage (0334333882): 42V
- Compatibility (15-2190): ESAB A-Series automated plasma cutting systems
- Compatibility (0334333882): ESAB A2 Automation, ESAB A6 Automation heads
- Controller Compatibility: ESAB PEK or A2-A6 process controllers
- Component Type: Linear Slide / Mechanical Carriage
- Packaging: Pack of 1
- Construction: Hardened guides and dust-sealed components
Applications
- Automated plasma cutting systems
- Submerged Arc Welding (SAW) automation
- MIG/MAG automated welding heads
- Beam and girder fabrication lines
- Pressure vessel manufacturing
- Pipe welding stations
- Retrofitting manual slides to motorized systems
- Heavy industrial fabrication
